FM-B PH4 Customized Outdoor LED Display Screen 256mmx128mm High Contrast wide viewing angle
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | Highmight |
| Certification: | CE FCC RoHS |
| Model Number: | FM-B PH4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | >=1 pieces |
|---|---|
| Price: | one module price |
| Packaging Details: | Flight case/wooden case/carton case packing |
| Delivery Time: | 7-35 work days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Panel Size: | 256mmx128mm | Type: | LED |
|---|---|---|---|
| Application: | Outdoor | Color: | Full Color |
| Resolution: | 64x32 | Pixel Pitch: | 4mm |
| Brightness: | 4500-7500 Cd/㎡ | Pixel Density: | 62500 Dot/㎡ |
| Lifespan (hours): | ≥100000H | IP Rating: | IP65 |
| HS Code: | 8528591090 | Refresh Rate: | 1920HZ/3840HZ |
| LED Chip: | SMD1921 | Scan Mode: | 1/8 Scan |
| Highlight: | Outdoor LED Display Screen High Contrast,Customized Outdoor LED Display Screen,256mmx128mm LED Screen P4 Outdoor |
||
Product Description
FM-B PH4 256mmx128mm high contrast and wide viewing angle Customized Outdoor LED Display Screen
Detailed product introduction document:Outdoor fixed sheet metal box FM-B series.pdf
Applicable scenarios:
1. commercial real estate , stage performance
2. welcome display and restaurant
3. stage performance
4. Subway/Metro Station
5. Floor and Ceiling Display and Media Advertising
Features:
1. high permeability, high refresh and high gray scale
2. Arbitrary customization: can be customized into square, triangle, circle, cylinder (can be curved into arc) and other irregular shapes
3. good heat dissipation
4. ultra high brightness and High definition
5. We introduced advanced technology equipment, we can delivery products on time, no matter samples or customized products
6. Support front and rear maintenance to reduce maintenance costs: the playback screen appears in a suspended style, which will not affect the building's lighting and vision.
7. We have experienced technology enginners team and sales team to answer and solve all your concerned matters.
Product Details
Models: FM-B PH4
| Pixel Pitch (mm) | 4 | Maximum Power (W/㎡) | 1000-1200W |
| Pixel Density (dot/㎡) | 62500 | Conventional Power (W/㎡) | 400-600W |
| Module Pixel | 64x32 | LED Composition | RGB three in one |
| Module Size | 256x128 | Eliminate Shadows | Equipment |
| Refresh Rate (HZ) | 1920/3840 | Input Voltage | AC100～240V 50/60HZ |
| Scan Mode | 1/8 Scan | Module Input Voltage | DC4.7～5V±0.2V |
| Lamp Type | SMD1921 | Module Thickness(mm) | 15.6 |
| Brightness (cd/㎡) | 4500-7500 | Cabinet Size | Customized |
| Lifespan (hours) | ≥100,000H | Gray Scale | 14bit |
| Working Temperature and Humidity | Temperature:-10～40℃ Humidity:10％-90％ | Installation | Magnetic installation / Cabinet installation |
