High Precision Custom LED Display Screen For Advertising Outdoor
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | Highmight |
| Certification: | CE FCC RoHS |
| Model Number: | FM-A-PH5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | >=1 pieces |
|---|---|
| Price: | one module price |
| Packaging Details: | Flight case/wooden case/carton case packing |
| Delivery Time: | 7-35 work days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Panel Size: | 320mmx160mm | Pixel Pitch: | 5mm |
|---|---|---|---|
| Specification: | Video Wall | Brightness: | 4500-7500 Cd/㎡ |
| Pixel Density: | 40000 Dot/㎡ | Lifespan (hours): | ≥100000H |
| IP Rating: | IP68 | HS Code: | 8528591090 |
| Resolution: | 64x32 | Refresh Rate: | 1920HZ/3840HZ |
| LED Chip: | SMD1921 | Scan Mode: | 1/8 Scan |
| Name: | LED Display Screen For Advertising Outdoor | ||
| Highlight: | Custom LED Display Outdoor Advertising,High Precision Custom LED Display Screen,Custom LED Display Screen For Advertising Outdoor |
||
Product Description
FM-A PH5 Customized Outdoor high precision LED Display Screen advertising led screen
Detailed product introduction document:PH6-PH10 outdoor fixed sheet metal box FM-A series...
Applicable scenarios:
1. commercial real estate , stage performance
2. welcome display and restaurant
3. stage performance
4. Subway/Metro Station
5. Floor and Ceiling Display and Media Advertising
6. Interior Decoration
Features:
1. high permeability, high refresh and high gray scale
2. Arbitrary customization: can be customized into square, triangle, circle, cylinder (can be curved into arc) and other irregular shapes
3. Thin and light multi occasion use fall resistant shockproof
4. ultra high brightness and High definition
5. Customize display screen
6. Support front and rear maintenance to reduce maintenance costs: the playback screen appears in a suspended style, which will not affect the building's lighting and vision.
Product Details
Models: FM-A
| Pixel Pitch (mm) | 5 | Maximum Power (W/㎡) | 1000-1200W |
| Pixel Density (dot/㎡) | 40000 | Conventional Power (W/㎡) | 400-600W |
| Module Pixel | 64x32 | LED Composition | RGB three in one |
| Module Size | 320x160 | Eliminate Shadows | Equipment |
| Refresh Rate (HZ) | 1920/3840 | Input Voltage | AC100～240V 50/60HZ |
| Scan Mode | 1/8 Scan | Module Input Voltage | DC4.7～5V±0.2V |
| Lamp Type | SMD1921 | Module Thickness(mm) | 15.6 |
| Brightness (cd/㎡) | 4500-7500 | Cabinet Size | Customized |
| Lifespan (hours) | ≥100,000H | Gray Scale | 14bit |
| Working Temperature and Humidity | Temperature:-10～40℃ Humidity:10％-90％ | Installation | Magnetic installation / Cabinet installation |
