FM-B PH6 Outdoor LED Display Screen For Advertising 192mmx192mm Customized
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | Highmight |
| Certification: | CE FCC RoHS |
| Model Number: | FM-B PH6 |
Payment & Shipping Terms:
| Minimum Order Quantity: | >=1 pieces |
|---|---|
| Price: | one module price |
| Packaging Details: | Flight case/wooden case/carton case packing |
| Delivery Time: | 7-35 work days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Name: | P6 Outdoor LED Display Screen | Panel Size: | 192mmx192mm |
|---|---|---|---|
| Pixel Pitch: | 6mm | Brightness: | 4500-7500 Cd/㎡ |
| Pixel Density: | 27777 Dot/㎡ | Lifespan (hours): | ≥100000H |
| IP Rating: | IP65 | Resolution: | 32x32 |
| Refresh Rate: | 1920HZ/3840HZ | LED Chip: | SMD2727/SMD3535 |
| Scan Mode: | 1/8 Scan | ||
| Highlight: | P6 Outdoor LED Display Screen,Outdoor LED Display Screen For Advertising,Outdoor P6 LED Display Screen |
||
Product Description
FM-B PH6 192mmx192mm Customized Outdoor LED Display Screen advertising led screen
Detailed product introduction document:Outdoor fixed sheet metal box FM-B series.pdf
Applicable scenarios:
1. commercial real estate , stage performance
2. welcome display and restaurant
3. stage performance
4. radio and television studios
5. Floor and Ceiling Display and Media Advertising
6. Interior Decoration
Features:
1, outdoor waterproof: positive/back waterproof grade ip65;
2, HD display perfect level of enjoyment: 16Bits high gray level, 1920 high refresh, live switching without flicker;
3, fast, simple, convenient: multi-functional link, more stable, convenient, safe;
4, support arc splicing: can be customized arc lock, support multi-angle installation, splicing box seamless splicing;
5, convenient mixing: H500/H1000 box module common, play screen diversification;
6, high brightness: support indoor and outdoor universal.
Product Details
Models: FM-B PH6
| Pixel Pitch (mm) | 6 | Maximum Power (W/㎡) | 1000-1200W |
| Pixel Density (dot/㎡) | 27777 | Conventional Power (W/㎡) | 400-600W |
| Module Pixel | 32x32 | LED Composition | RGB three in one |
| Module Size | 192x192 | Eliminate Shadows | Equipment |
| Refresh Rate (HZ) | 1920/3840 | Input Voltage | AC100～240V 50/60HZ |
| Scan Mode | 1/8 Scan | Module Input Voltage | DC4.7～5V±0.2V |
| Lamp Type | SMD2727/SMD3535 | Module Thickness(mm) | 15.6 |
| Brightness (cd/㎡) | 4500-7500 | Cabinet Size | Customized |
| Lifespan (hours) | ≥100,000H | Gray Scale | 14bit |
| Working Temperature and Humidity | Temperature:-10～40℃ Humidity:10％-90％ | Installation | Magnetic installation / Cabinet installation |
Application:
