Full Color Small Pixel Pitch LED Panel 500-600 Cd/M2 Front Maintenance
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | Highmight |
| Certification: | CE FCC RoHS |
| Model Number: | HMT-XM |
Payment & Shipping Terms:
| Minimum Order Quantity: | >=1 square meters |
|---|---|
| Price: | $7,780.00/square meters >=1 square meters |
| Packaging Details: | Flight case/wooden case/carton case packing |
| Delivery Time: | 7-35 work days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Name: | Small Pixel Pitch LED Panel | Color: | Full Color |
|---|---|---|---|
| Panel Size: | 640mmx480mmx61mm | Media Available: | Datasheet, Photo |
| Application: | Indoor | Brightness: | 600 Cd/㎡ |
| Contrast Ratio: | ≥5000:1 | Lifespan (hours): | ≥100000H |
| HS Code: | 8528591090 | Material: | Die-casting Aluminum |
| Maintenance: | Front Maintenance | Refresh Rate: | 1920/3840 |
| LED Chip: | SMD1010 | Maximum Power(W/㎡): | 300-400W |
| Highlight: | Small Pixel Pitch LED Panel 800 Cd/M2,Full Color Small Pixel LED Panel |
||
Product Description
Full Color Small Pixel Pitch LED Panel 500-800 Cd/M2 Front Maintenance MINI 4in1 LED Chip XM-PH1.2
Applicable scenarios :
1. command center
2. energy control room
3. government and enterprise conference hall
4. radio and television studio
5. education and training centre
6. exhibition display
Features:
1. Ultra-thin 16:9 gold display ratio, easy to achieve 4K/8K broadcast HD;
2. With 125% of the NTSC color gamut of broadcast grade, it has excellent color expression and reduction;
3. It has the functions of dustproof, shockproof, anti-collision, moisture-proof, anti-oxidation, anti-static, etc;
Product Details
Models: XM
| Pixel Pitch (mm) | 1.25 | Refresh Rate (HZ) | 3840 |
| Module Size (mm) | 320x160 | Contrast Ratio | ≥5000:1 |
| Module Pixel | 256x128 | Conventional Power (W/㎡) | 400-600W |
| Pixel Density (dot/㎡) | 288906 | Gray Scale | 16bit |
| Lamp Type | SMD1515 | LED Composition | RGB three in one |
| Brightness (cd/㎡) | 500-800 | protection level | IP65 |
| Scan Mode | 1/43 Scan | Eliminate Shadows | Equipment |
| Module Thickness (mm) | 17 | Input Voltage | AC100～240V 50/60HZ |
| Cabinet Size (mm) | 640x480 | Module Input Voltage | DC4.7～5V±0.2V |
| Cabinet Pixel | 344x258 | Cabinet Weight | 7.2kg |
| Cabinet Thickness (mm) | 32.5 | Cabinet Material | Sheet Metal |
| Lifespan (Hours) | ≥100,000H | Maintenance | front/rear maintenance |
| Working Temperature and Humidity | Temperature:-10～40℃ Humidity:10％-90％ | Installation | fixed installation |
| Signal Connection | WiFi / DVI / HDMI / DP / USB / RJ45 network cable / remote control system | Control System | Nova / Colorlight System / Magnimade System / Mooncell System |
Application:
FQA:
1. When did your company start the LED display business?
A: Highmight Technology was founded in 2004, the same year began to produce monochrome, two-color and LCD screens, and then began to full-color LED displays. We have 16 years of complete LED display manufacturing experience.
2. What is the delivery time of your LED display?
A: Our standard LED display manufacturing time is 15-20 business days, including 72 hours of shop burn-in testing.
For particularly popular LED displays, we may have them in stock. Please contact our sales engineer to see if we can have a faster delivery time.
3. Creative LED display?
A: We have creative LED displays. For example, flexible LED screen, LED transparent ball, LED cube screen and so on.
