XM-II PH1.8 Small Pixel Pitch LED Screen For Radio / Television Studio
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | Highmight |
| Certification: | CE FCC RoHS |
| Model Number: | XM-II PH1.8 |
Payment & Shipping Terms:
| Minimum Order Quantity: | >=1 square meters |
|---|---|
| Price: | $880.00/square meters >=1 square meters |
| Packaging Details: | Flight case/wooden case/carton case packing |
| Delivery Time: | 7-35 work days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Name: | Small Pixel Pitch LED Screen | Panel Size: | 640mmx480mm |
|---|---|---|---|
| Pixel Pitch: | 1.8mm | Brightness: | 500-800 Cd/㎡ |
| Pixel Density: | 288906 Dot/㎡ | Contrast Ratio: | ≥5000:1 |
| Lifespan (hours): | ≥100000h | Resolution: | 344x258 |
| Material: | Die-casting Aluminum | Refresh Rate: | 3480HZ |
| Module Size: | 320x160 | ||
| Highlight: | 1.8mm Small Pixel Pitch LED Screen,RoHS Small Pixel Pitch LED Screen,FCC Small Pixel Pitch LED Display |
||
Product Description
XM-II PH1.8 small pixel pitch led screen for radio and television studio
Detailed product introduction document:Small Pitch XM-II Series.pdf
Applicable scenarios:
1. command center
2. energy control room
3. government and enterprise conference hall
4. radio and television studio
5. education and training centre
6. exhibition display
Features:
1. high refresh and high gray scale
2. LED screen is easy to carry, transport and install - saving good amount of money on your labor costs. LED
3. The thinnest display body in the industry, lighter weight, more beautiful when installed close to the wall, and the installation surface can bear load without pressure;
4. 16:9 standard display ratio, suitable for security audio-visual applications;
5. High grayscale, high refresh lossless display technology.
6.High refresh, high brightness
7.Broadcast-level color gamut, color temperature intelligent adjustable
Using RBG three-color imaging technology to achieve broadcast leve standards, after single-point brightness, chroma correction
Product Details
Models: XM-II PH1.8
| Pixel Pitch (mm) | 1.8605 | Refresh Rate (HZ) | 3840 |
| Module Size (mm) | 320x160 | Contrast Ratio | ≥5000:1 |
| Module Pixel | 172x86 | Conventional Power (W/㎡) | 400-600W |
| Pixel Density (dot/㎡) | 288906 | Gray Scale | 16bit |
| Lamp Type | SMD1515 | LED Composition | RGB three in one |
| Brightness (cd/㎡) | 500-800 | protection level | IP65 |
| Scan Mode | 1/43 Scan | Eliminate Shadows | Equipment |
| Module Thickness (mm) | 17 | Input Voltage | AC100～240V 50/60HZ |
| Cabinet Size (mm) | 640x480 | Module Input Voltage | DC4.7～5V±0.2V |
| Cabinet Pixel | 344x258 | Cabinet Weight | 7.2kg |
| Cabinet Thickness (mm) | 32.5 | Cabinet Material | Sheet Metal |
| Lifespan (Hours) | ≥100,000H | Maintenance | front/rear maintenance |
| Working Temperature and Humidity | Temperature:-10～40℃ Humidity:10％-90％ | Installation | fixed installation |
| Signal Connection | WiFi / DVI / HDMI / DP / USB / RJ45 network cable / remote control system | Control System | Nova / Colorlight System / Magnimade System / Mooncell System |
