XM-II PH1.5 High Grayscale Narrow Pixel Pitch LED Display Screen 640mmx480mm
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | Highmight |
| Certification: | CE FCC RoHS |
| Model Number: | XM-II PH1.5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | >=1 square meters |
|---|---|
| Price: | $1,314.00/square meters >=1 square meters |
| Packaging Details: | Flight case/wooden case/carton case packing |
| Delivery Time: | 7-35 work days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Pixel Pitch: | 1.5MM | Brightness: | 500-800 Cd/㎡ |
|---|---|---|---|
| Pixel Density: | 422500 Dot/㎡ | Panel Size: | 640mmx480mm |
| Contrast Ratio: | ≥5000:1 | Lifespan (hours): | ≥100000h |
| Resolution: | 416x312 | Refresh Rate: | 3480HZ |
| LED Chip: | SMD1212 | Material: | Die-casting Aluminum |
| Highlight: | High Grayscale Narrow Pixel Pitch LED Display,Narrow Pixel Pitch LED Display Screen |
||
Product Description
XM-II PH1.5 High Grayscale High Refresh Small Pixel Pitch LED Display Screen
Detailed product introduction document:Small Pitch XM-II Series.pdf
Applicable scenarios:
1.Cultural tourism
2.Smart city
3. government and enterprise conference hall
4. radio and television studio
5. education and training centre
6.Seamless stitching
Features:
1. high refresh and high gray scale
2. LED screen is easy to carry, transport and install - saving good amount of money on your labor costs. LED
3. The thinnest display body in the industry, lighter weight, more beautiful when installed close to the wall, and the installation surface can bear load without pressure;
4. 16:9 standard display ratio, suitable for security audio-visual applications;
Product Details
Models: XM-II PH1.5
| Pixel Pitch (mm) | 1.538 | Refresh Rate (HZ) | 3840 |
| Module Size (mm) | 320x160 | Contrast Ratio | ≥5000:1 |
| Module Pixel | 208x104 | Conventional Power (W/㎡) | 400-600W |
| Pixel Density (dot/㎡) | 422500 | Gray Scale | 16bit |
| Lamp Type | SMD1212 | LED Composition | RGB three in one |
| Brightness (cd/㎡) | 500-800 | protection level | IP65 |
| Scan Mode | 1/52 Scan | Eliminate Shadows | Equipment |
| Module Thickness (mm) | 17 | Input Voltage | AC100～240V 50/60HZ |
| Cabinet Size (mm) | 640x480 | Module Input Voltage | DC4.7～5V±0.2V |
| Cabinet Pixel | 416x312 | Cabinet Weight | 7.8kg |
| Cabinet Thickness (mm) | 32.5 | Cabinet Material | Sheet Metal |
| Lifespan (Hours) | ≥100,000H | Maintenance | front/rear maintenance |
| Working Temperature and Humidity | Temperature:-10～40℃ Humidity:10％-90％ | Installation | fixed installation |
| Signal Connection | WiFi / DVI / HDMI / DP / USB / RJ45 network cable / remote control system | Control System | Nova / Colorlight System / Magnimade System / Mooncell System |
