Full Color Indoor LED Display Screen Wide Viewing Angle P PH5 320mmx160mm
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | Highmight |
| Certification: | CE FCC RoHS |
| Model Number: | P PH5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | >=1 square meters |
|---|---|
| Price: | $220.00/square meters >=1 square meters |
| Packaging Details: | Flight case/wooden case/carton case packing |
| Delivery Time: | 7-35 work days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Application: | Indoor | Type: | LED |
|---|---|---|---|
| Color: | Full Color | Panel Size: | 320mmx160mm |
| Pixel Pitch: | 5mm | Specification: | Video Wall |
| Brightness: | 500-800 Cd/㎡ | Pixel Density: | 40000 Dot/㎡ |
| Lifespan (hours): | ≥100000H, ≥100000H | HS Code: | 8528591090 |
| Resolution: | 64x32 | Refresh Rate: | 1920HZ/3840HZ |
| Weight: | 30kg/㎡ | Scan Mode: | 1/16 Scan |
| Highlight: | Full Color Indoor LED Display Screen,Indoor LED Display Screen Full Color,FCC Indoor Full Color LED Display Screen |
||
Product Description
P PH5 320mmx160mm Indoor small led lamp pitch wide viewing angle LED display screen
Detailed product introduction document:PH5 (P series module).pdf
Applicable scenarios:
1. command center
2. energy control room
3. government and enterprise conference hall
4. radio and television studio
5.Movie and drama screen,
6.Party screen,
7.Network video conferencing,
8.Schools and educational institutions
Features:
1. Strong and durable, long life
2. Energy saving and environmental protection, not affected by ambient light, easy to install
3. Large screen splicing, superior display performance
4. Self-made kit mold, with good flatness, no deformation, strong oxidation resistance, and more stable use;
5. More flexible installation and more convenient maintenance.
Product Details
Models: P PH5
| Pixel Pitch (mm) | 5 | Refresh Rate (HZ) | 3840 |
| Module Size (mm) | 320x160 | Contrast Ratio | ≥5000:1 |
| Module Pixel | 64x32 | Conventional Power (W/㎡) | 400-600W |
| Pixel Density (dot/㎡) | 40000 | Gray Scale | 16bit |
| Lamp Type | SMD2121 | LED Composition | RGB three in one |
| Brightness (cd/㎡) | 500-800 | protection level | IP65 |
| Scan Mode | 1/16Scan | Eliminate Shadows | Equipment |
| Module Thickness (mm) | 13 | Input Voltage | AC100～240V 50/60HZ |
| Cabinet Size (mm) | 640x480 | Module Input Voltage | DC4.7～5V±0.2V |
| Cabinet Pixel | 416x312 | Cabinet Weight | 30kg |
| Cabinet Thickness (mm) | 32.5 | Cabinet Material | Sheet Metal |
| Lifespan (Hours) | ≥100,000H | Maintenance | front/rear maintenance |
| Working Temperature and Humidity | Temperature:-10～40℃ Humidity:10％-90％ | Installation | fixed installation |
| Signal Connection | WiFi / DVI / HDMI / DP / USB / RJ45 network cable / remote control system | Control System | Nova / Colorlight System / Magnimade System / Mooncell System |
Application:
