256mmx128mm Indoor Video Wall Display / LED Commercial Advertising Display Screen V PH2
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | Highmight |
| Certification: | CE FCC RoHS |
| Model Number: | V PH2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | >=1 square meters |
|---|---|
| Price: | $730.00/square meters >=1 square meters |
| Packaging Details: | Flight case/wooden case/carton case packing |
| Delivery Time: | 7-35 work days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Name: | LED Commercial Advertising Display Screen | Type: | LED |
|---|---|---|---|
| Color: | Full Color | Panel Size: | 256mmx128mm |
| Pixel Pitch: | 2mm | Application: | Indoor |
| Specification: | Video Wall | Brightness: | 500-800 Cd/㎡ |
| Pixel Density: | 250000 Dot/㎡ | Lifespan (hours): | ≥100000H |
| HS Code: | 8528591090 | Resolution: | 128x64 |
| Refresh Rate: | 1920HZ/3840HZ | Scan Mode: | 1/32 Scan |
| Highlight: | LED Commercial Advertising Display Screen,Advertising LED Wall Display Screen,256mmx128mm Indoor Video Wall Display |
||
Product Description
V PH2 320mmx160mm Indoor Full Color high brightness LED display screen
Detailed product introduction document:PH2 (V Series Module).pdf
Applicable scenarios:
1.Conference screen,
2.Wedding screen,
3.Hotel screen,
4.Entertainment commercial display,
5.Entertainment bar KTV
6.Mid-sized concert
Features:
1. Strong and durable, long life
2. Energy saving and environmental protection, not affected by ambient light, easy to install
3. Large screen splicing, superior display performance
4. Support graphics correction technology to ensure consistency of brightness, grayscale, and chroma;
5. Supports multiple combinations of unit modules + chassis to meet various complex needs of project scenarios;
6. Self-made kit mold, with good flatness, no deformation, strong oxidation resistance, and more stable use;
7. More flexible installation and more convenient maintenance.
One-button design, abandon redundancy, easy to operate;
Ultra-thin design, beautiful atmosphere;
Front-end installation and front-end maintenance;
Product Details
Models: V PH2
| Pixel Pitch (mm) | 2 | Refresh Rate (HZ) | 3840 |
| Module Size (mm) | 256x128 | Contrast Ratio | ≥5000:1 |
| Module Pixel | 160x80 | Conventional Power (W/㎡) | 400-600W |
| Pixel Density (dot/㎡) | 250000 | Gray Scale | 16bit |
| Lamp Type | SMD1515 | LED Composition | RGB three in one |
| Brightness (cd/㎡) | 500-800 | protection level | IP65 |
| Scan Mode | 1/40Scan | Eliminate Shadows | Equipment |
| Module Thickness (mm) | 13 | Input Voltage | AC100～240V 50/60HZ |
| Cabinet Size (mm) | 640x480 | Module Input Voltage | DC4.7～5V±0.2V |
| Cabinet Pixel | 416x312 | Cabinet Weight | 30kg |
| Cabinet Thickness (mm) | 32.5 | Cabinet Material | Sheet Metal |
| Lifespan (Hours) | ≥100,000H | Maintenance | front/rear maintenance |
| Working Temperature and Humidity | Temperature:-10～40℃ Humidity:10％-90％ | Installation | fixed installation |
| Signal Connection | WiFi / DVI / HDMI / DP / USB / RJ45 network cable / remote control system | Control System | Nova / Colorlight System / Magnimade System / Mooncell System |
Application:
