indoor Transparent LED Screen Display IP65 Dustproof And Waterproof PH15-15
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | HighMight |
| Certification: | CE FCC RoHS |
| Model Number: | TRA-B PH15-15 |
Payment & Shipping Terms:
| Minimum Order Quantity: | >=1 square meters |
|---|---|
| Price: | $770.00/square meters |
| Packaging Details: | Flight case/wooden case/carton case packing |
| Delivery Time: | 7-35 work days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Application: | Indoor | Type: | LED |
|---|---|---|---|
| Color: | Full Color | Panel Size: | 500mm*1000mm |
| Pixel Pitch: | 15.6-15.6 | Brightness: | ≥4500 Cd/㎡ |
| Pixel Density: | 4096 Dot/㎡ | Lifespan (hours): | ≥100000H |
| IP Rating: | IP65 | Resolution: | 64X64 |
| Highlight: | Transparent LED Screen Display IP65,Outdoor Transparent LED Screen Display,transparent led display Waterproof |
||
Product Description
indoor Transparent LED Screen Display IP65 Dustproof And Waterproof TRA-B 15-15
Detailed product introduction document:Indoor transparent screen TRA-B series.pdf
Applicable scenarios :
1. stage performance
2. Outdoor Fence & Partition
3. Subway/Metro Station
4. Green energy saving, good heat dissipation performance
5.LED transparent screen is easy to maintain
6. Save building lighting costs
Features:
1. Transparent and invisible, see the shadow but not the screen
2. IP65 dustproof and waterproof , curve design available
3. Clear picture without flicker and distortion.No light leakage trouble
4. high contrast and wide viewing angle
5. High refresh rate and gray scale ensures the picture quality remains seamless
6. Providing excellent customer service and technical support
7. fast assembling high contrast and wide viewing angle
Product Details
Models: TRA-B 5-10
| Pixel Pitch (mm) | 15.6-15.6 | Conventional Power (W/㎡) | 400-600W |
| Signal Connection | WiFi / DVI / HDMI / DP / USB / RJ45 network cable / remote control system | Control System | Nova / Colorlight System / Magnimade System / Mooncell System |
| Pixel Density (dot/㎡) | 4096 | Transparency | 75% |
| Cabinet Pixel | 64X64 | Protection Grade | IP65 |
| Refresh Rate (HZ) | 3840Hz | Eliminate Shadows | Equipment |
| Driver Chip | ICN2038S(same level) | Input Voltage | AC100～240V 50/60HZ |
| Scan Mode | static | Module Input Voltage | DC4.7～5V±0.2V |
| Lamp Type | SMD2727 | Cabinet Size (mm) | 1000X500X80 |
| Brightness (cd/㎡) | ≥4500 | Weight (kg/㎡) | 12kg/㎡ |
| Lifespan (hours) | ≥100,000H | Cabinet Material | Die-casting Alumimum |
| Working Temperature and Humidity | Temperature:-10～40℃ Humidity:10％-90％ | Maintenance |
power/Control System : rear maintenance module:front maintenance |
| LED Composition | RGB three in one | Gray Scale | 14bit |
| Maximum Power (W/㎡) | 600-800W | Installation | hoisting/fixed installation/Build on standing structure |
Application:
FQA:
Q1: How is the quality of the product?
A: Our products have been strictly tested before out of our factory. Strict quality management and control process are assured before shipping to customers.
