Waterproof Outdoor LED Screen 500*500mm Die Casting Aluminum LED Display
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | Highmight |
| Certification: | CE FCC RoHS |
| Model Number: | RS-A |
Payment & Shipping Terms:
| Minimum Order Quantity: | >=1 square meters |
|---|---|
| Price: | $710~1352/square meters |
| Packaging Details: | Flight case/wooden case/carton case packing |
| Delivery Time: | 7-35 work days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Type: | LED | Color: | Full Color |
|---|---|---|---|
| Media Available: | Datasheet, Photo | Specification: | Video Wall |
| Color Scale: | 14bit | Lifespan (hours): | ≥100000H |
| IP Rating: | Front IP65 And Rear IP54 | Refresh Rate: | 1920HZ/3840HZ |
| Material: | Die-casting Aluminum | Installation: | Ixed Installation / Hoisting / Build On Standing Structure |
| Highlight: | Waterproof Outdoor LED Screen 500*500mm,RoHS Waterproof LED Display Screen,Die Casting Aluminum LED Display |
||
Product Description
Outdoor 500*500 Waterproof Die Casting Aluminum Rental LED display screen high brightness
Detailed product introduction document:Outdoor rental screen RS-A series (soft connection...
Applicable scenarios:
1. stage performance
2. new product presentation
3. Advertising activities
4. training and airport
5. banquet activities
Features:
1. High definition display with ideal enjoyment: 16Bits high grayscale and more than 1920Hz refresh rate enable no flicker during live streaming signal switch;
2. Ultra-thin cabinet, the whole cabinet is made of aluminum alloy or magnesium alloy material, Faster and easier installation
3. We have experienced technology enginners team and sales team to answer and solve all your concerned matters.
4. Convenient Mix & Match: The H500/H1000 module is universal,can splice and display in diversity.
5. Perfect enjoyment of high-definition display: 16Bits high grayscale, high refresh rate above 1920, no flicker during live switching;
6. It delivers an image which is super subtle and without getting tired after a longtime watching
Product Details
Models:RS-A
| Rental LED display screen (RS-A series) | ||||
| Models | RS-A 2.604 | RS-A 2.976 | RS-A 3.91 | RS-A 4.81 |
| Pixel Pitch (mm) | 2.604 | 2.976 | 3.91 | 4.81 |
| Module size (mm) | 250x250 | 250x250 | 250x250 | 250x250 |
| Module pixel | 96x96 | 84x84 | 64x64 | 52x52 |
|
Pixel Density (dot/㎡) |
147456 | 112896 | 65536 | 43264 |
| LED Lamp Type | SMD1415 | SMD1415 | SMD1921 | SMD1921 |
| Brightness (cd/㎡) | 4000 | 4500 | 4500 | 4500 |
| Refresh rate (Hz) | 1920/3840 | 1920/3840 | 1920/3840 | 1920/3840 |
| Scan Mode | 1/24 Scan | 1/21 Scan | 1/16 Scan | 1/13 Scan |
| Module thickness (mm) | 15 | 15 | 15 | 15 |
| Cabinet size (mm) | 500x500/500x1000 | 500x500/500x1000 | 500x500/500x1000 | 500x500/500x1000 |
| Cabinet pixel | 192x192/192x384 | 168x168/168x336 | 128X128/128X256 | 104X104/104X208 |
| Module+Cabinet thickness (mm) | 15+75=90 | 15+75=90 | 15+75=90 | 15+75=90 |
| Lifespan (hours) | ≥ 100,000 hours | |||
| LED Composition | RGB three-in-one | |||
| Grey scale | 14bit | |||
|
Maximum power (W/㎡) |
800W | |||
| Conventional power (W/㎡) | 600W | |||
| Control System | Nova / Colorlight System / Magnimade System / Mooncell System | |||
| Signal Connection | WiFi / DVI / HDMI / DP / USB / RJ45 network cable / remote control system | |||
| the protection grades | IP30 | |||
| Eliminate Shadows | Equipment | |||
| input voltage | AC100～240V 50/60HZ | |||
| Module input voltage | DC4.7～5V±0.2V | |||
| Working temperature and humidity | Temperature: -10～40℃ Humidity: 10％-90％ | |||
| Weight (kg) | 7.5kg(500x500 ) /16kg(500x1000 ) | |||
| Cabinet material | Die casting aluminum | |||
| Maintenance | rear maintenance | |||
| Installation | hoisting/fixed installation/Build on standing structure | |||
Application:
