LED customized outdoor aluminum cabinet specification It can operate normally during thunderstorms and other bad weather
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | Highmight |
| Certification: | CE FCC RoHS |
| Model Number: | FA-X PH8 |
Payment & Shipping Terms:
| Minimum Order Quantity: | >=1 pieces |
|---|---|
| Price: | Customized price |
| Packaging Details: | Flight case/wooden case/carton case packing |
| Delivery Time: | 7-35 work days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Type: | LED | Panel Size: | 480mmx320mm |
|---|---|---|---|
| Color: | Full Color | Pixel Pitch: | 8mm |
| Physical Pixels (dot/㎡): | 15625 | Brightness: | 4000-8000 Cd/㎡ |
| Lamp Bead Working Life: | ≥ 100,000 Hours | Contrast Ratio: | ≥5000:1 |
| Refresh Rate: | 3840HZ | Module Size: | Customizable |
| LED Lamp Bead Model: | SMD2727 | Scan Method: | 1/4sweep |
| Grayscale: | 14bit | Maximum Power (W/㎡)resolution: | 650W |
| Highlight: | Customized Small Pixel Pitch LED Screen,1.8mm Small Pixel Pitch LED Screen Indoor,Custom Size LED Screen Indoor |
||
Product Description
FA-X 480mmx320mm Customized Outdoor waterproof and dustproof LED Display Screen
Detailed product introduction document:Outdoor fixed installation front maintenance FA-X ...
Applicable scenarios:
1. commercial real estate , stage performance
2. welcome display and restaurant
3. shopping mall glass curtain wall
4. Subway/Metro Station
5. Floor and Ceiling Display and Media Advertising
6. Interior Decoration and Super Market
Features:
1. high permeability, high refresh and high gray scale
2. We have experienced technology enginners team and sales team to answer and solve all your concerned matters.
3. good heat dissipation
4. ultra high brightness and High definition
5. Unique sealing and filling technology: sealing and filling technology not only protects the lamp beads, but also has a waterproof effect, and the waterproof level is as high as IP65
6. The best price. You are welcome to contact us for a free project evaluation.
Product Details
| LED outdoor fixed front maintenance FA-X series | |||||
| Module model (mm) | FA-X 4.4 | FA-X 5.7 | FA-X 6.6 | FA-X 8 | FA-X 10 |
| Module point spacing (mm) | 4.44 | 5.71 | 6.66 | 8 | 10 |
| Module Size (mm) | 480x320 | 480x320 | 480x320 | 480x320 | 480x320 |
| Module pixel | 108x72 | 84x56 | 72x48 | 60x40 | 48x32 |
| PCB | 4 | 4 | 2 | 2 | 2 |
| Maximum current | 22A | 22A | 22A | 22A | 22A |
| Density pixels (dot/㎡) | 50630 | 30625 | 22500 | 15625 | 10000 |
| Lamp bead model | SMD1921 | SMD2727 | SMD2727 | SMD2727 | SMD2727 |
| Brightness (cd/㎡) | ≤6000 | ≤6000 | ≤6000 | ≤6000 | ≤6000 |
| Refresh rate (Hz) | 3840 | 3840 | 3840 | 3840 | 3840 |
| Scanning mode | 1/9sweep | 1/7sweep | 1/6sweep | 1/4sweep | 1/2sweep |
| Box size (mm) | 960x960x77 | 960x960x77 | 960x960x77 | 960x960x77 | 960x960x77 |
| Cabinet resolution | 216x216 | 168x168 | 144x144 | 120x120 | 96x96 |
| Lamp working life | ≥100,000 hours | ||||
| Pixel composition | RGB 3-in-1 | ||||
| Grayscale | 14bit | ||||
| Maximum power (W/㎡) | 1000-1200W | ||||
| Conventional power (W/㎡) | 400-600W | ||||
| Eliminate ghosting | Equipment | ||||
| Input voltage | AC100～240V 50/60HZ | ||||
| Module input voltage | DC4.7～5V±0.2V | ||||
| Work Environment | Temperature -10～40℃ Humidity 10％-90％ | ||||
| Box weight | 24.5kg | ||||
