Outdoor Naked Eye 3D LED Display Screen Customized 320mmx160mm
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | Highmight |
| Certification: | CE FCC RoHS |
| Model Number: | FM-A PH4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | >=1 pieces |
|---|---|
| Price: | Customized price |
| Packaging Details: | Flight case/wooden case/carton case packing |
| Delivery Time: | 7-35 work days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Application: | Outdoor | Type: | LED |
|---|---|---|---|
| Panel Size: | 320mmx160mm | Pixel Pitch: | 4mm |
| Specification: | Video Wall | Brightness: | 4500-7500 Cd/㎡ |
| Pixel Density: | 62500 Dot/㎡ | Lifespan (hours): | ≥100000H |
| IP Rating: | IP65 | Refresh Rate: | 1920HZ/3840HZ |
| LED Chip: | SMD1921 | Grayscale: | 14 Bit |
| Highlight: | Naked Eye 3D LED Display Screen,Naked Eye 3D LED Screen Display,Outdoor Naked Eye 3D LED Display |
||
Product Description
FM-A PH4 320mmx160mm Customized Outdoor Naked Eye 3D LED Display Screen
Detailed product introduction document:PH2.5-PH5 outdoor fixed sheet metal box FM-A serie...
Applicable scenarios :
1. commercial real estate , stage performance
2. welcome display and restaurant
3. stage performance
4. Subway/Metro Station
5. Floor and Ceiling Display and Media Advertising
6. Interior Decoration
Features:
1. high permeability, high refresh and high gray scale
2. Arbitrary customization: can be customized into square, triangle, circle, cylinder (can be curved into arc) and other irregular shapes
3. good heat dissipation
4. ultra high brightness and High definition
5. Unique sealing and filling technology: sealing and filling technology not only protects the lamp beads, but also has a waterproof effect, and the waterproof level is as high as IP65
6. support arc splicing: can be customized arc lock, support multi-angle installation, splicing box seamless splicing;
7. convenient mixing: H500/H1000 box module common, play screen diversification;
8. high brightness: support indoor and outdoor universal.
Product Details
Models: FM-A PH4
| Pixel Pitch (mm) | 4 | Maximum Power (W/㎡) | 1000-1200W |
| Pixel Density (dot/㎡) | 62500 | Conventional Power (W/㎡) | 400-600W |
| Module Pixel | 80x40 | LED Composition | RGB three in one |
| Module Size | 320x160 | Eliminate Shadows | Equipment |
| Refresh Rate (HZ) | 1920/3840 | Input Voltage | AC100～240V 50/60HZ |
| Scan Mode | 1/10 Scan | Module Input Voltage | DC4.7～5V±0.2V |
| Lamp Type | SMD1921 | Module Thickness(mm) | 15.6 |
| Brightness (cd/㎡) | 4500-7500 | Cabinet Size | Customized |
| Lifespan (hours) | ≥100,000H | Gray Scale | 14bit |
| Working Temperature and Humidity | Temperature:-10～40℃ Humidity:10％-90％ | Installation | Magnetic installation / Cabinet installation |
